| No. |
Technical parameters |
Technical index |
| 1 |
Output frequency |
0.4～18GHz |
| 2 |
Output power |
≥12dBm |
| 3 |
Output power precision |
≤2.0dB |
| 4 |
Output power dynamic |
≥70dB |
| 5 |
stray |
≤-50dBc |
| 6 |
Harmonic wave |
≤-25dBc (related to Output power) |
| 7 |
Phase noise |
≤-100dBc@1kHz (0.4-2.0GHz)
≤-90dBc@1kHz (2.0-8.0GHz)
≤-85dBc@1kHz (8.0-18GHz) |
| 8 |
stability |
Associated with the crystals |
| 9 |
Modulation Functions |
Impulse moisturiser modulation: 30 or less ns, 70 db or higher modulation depth (related to the modulation switch),
Frequency modulation, phase modulation |
| 10 |
Frequency-setting precision |
±10kHz |
| 11 |
Frequency-setting Stepping |
10kHz |
| 12 |
Frequency-setting time |
＜1uS |
| 13 |
amplitude switching time |
＜500ns |
| 14 |
Structure |
6U box or Can be customized |
