| No. |
Technical parameters |
Technical index |
Note |
| 1 |
Reference source frequency(MHz) |
10/13/25/100 (optional) |
|
| 2 |
Output frequency( Wave band ) |
P/L/S/C/X (optional) |
|
| 3 |
frequency Stepping |
1MHz/125KHz/1KHz/100Hz (optional) |
|
| 4 |
Lock indication |
TTL high level lock |
|
| 5 |
Output power (dBm) |
≥+13 |
|
| 6 |
Phase noise (dBc/Hz ) |
-75 @100Hz,
-85@1KHz
-95 @10KHz,
-105 @100KHz |
P/L/S Wave band |
-75 @100Hz, -85@1KHz
-90 @10KHz,
-105 @100KHz |
C/X Wave band |
-75 @100Hz, -85@1KHz
-90@10KHz,
-100@100KHz |
Ku Wave band |
| 7 |
stray Output (dBc) |
≤-70 |
|
| 8 |
Harmonic wave suppression (dBc) |
≤-40 |
|
| 9 |
Frequency hopping time (us) |
≤10 |
|
| 10 |
interface type |
SMA |
|
| 11 |
Standing wave ratio |
≤1.25:1 |
|
| 12 |
Voltage (V) |
DC+15 |
|
| 13 |
Current (mA) |
≤400 |
|
| 14 |
Working temperature |
-40℃～55℃ |
|
| 15 |
Overall dimensions (mm) |
(L×W×H) :125*65*20 |
|
