| No. |
Technical parameters |
Technical index |
| 1 |
Input Frequency range (MHz) |
950～1450 |
| 2 |
Output Frequency range (GHz) |
14.0～14.5 |
| 3 |
Local oscillator frequency (GHz) |
13.05 |
| 4 |
Reference source frequency (MHz) |
10MHz (provided by Intermediate frequency interface) |
| 5 |
Reference source level (dBm) |
0±2 |
| 6 |
P-1 (dBm) |
≥39 |
| 7 |
Gain (dB) |
≥60 |
| 8 |
Gain flatness (dB) |
≤±2.0 |
| 9 |
Intermodulation attenuation (dBc) |
≤-25 |
| 10 |
Phase noise (dBc/Hz) |
-65 @100Hz,
-75@1KHz
-85 @10KHz,
-95 @100KHz |
| 11 |
stray (dBc) |
≤-55 |
| 12 |
Supply voltage (V) |
+18～+36 (provided by Intermediate frequency interface) |
| 13 |
Working temperature (℃) |
-25 ～ +55 |
| 14 |
Relative humidity (%) |
45～75 |
| 15 |
Overall dimensions (mm) |
≤240mm*130mm*94mm(Regardless of the plugin) |
