| No. |
Technical parameters |
Technical index |
| 1 |
Working frequency (GHz) |
2.3～2.7 |
| 2 |
Transmission Output power (W) |
≥15 |
| 3 |
Transmission EVM(%) |
＜3 (64QAM) |
| 4 |
Transmission channel gain (dB) |
≥40 |
| 5 |
Transmission Gain flatness (dB) |
≤±1.5 |
| 6 |
Send and receive switch time (uS) |
≤2 |
| 7 |
Receiving Noise factor (dB) |
≤2.8 |
| 8 |
Receiving channel gain (dB) |
≥10 |
| 9 |
Receiving Gain flatness (dB) |
≤±1 |
| 10 |
Receiving Output P-1 (dBm) |
≥10 |
| 11 |
Receiving Not-damaged Input level(dBm) |
≥20 |
| 12 |
Harmonic wave (dBc) |
≤-55 |
| 13 |
clutter (dBc) |
≤-60 |
| 14 |
Transmission Output protection |
Output open and short circuit devices Not - on 30 minutes |
| 15 |
Control level of Receiving protection(dBm) |
When the identifiers signal attenuation 10 db > - 10 DBM identifiers channel gain |
| 16 |
Supply voltage(V) |
+24/+5 |
| 17 |
Radio frequency interface |
MCX-KYD3 |
| 18 |
Working temperature (℃) |
-45～+85 |
| 19 |
Overall dimensions (mm) |
(L*W*H) 145*65*22 (Regardless of the plugin) |
